เพาเวอร์ TaFn รุ่น ATOM 3200

Share

Share

Specifications

Sensitivity for full rated power
0.7 Volts RMS
Frequency Response 20 Hz to 20 KHz
1.5dB   at any power level
Signal to Noise ratio 20 Hz to 20 KHz
More than 105 dB
Total Harmonic Distortion (THD)
0.1%
Intermodulation Distortion (IMD)
0.05%
Damping Factor
600 From 20 Hz to 1K Hz.
Load Impedance
Safe with all types of loads
Output power stereo mode at  8 ohm      (stereo)
850 + 850 Watts RMS   (both channels driven)
Output power stereo mode at  4 ohm      (stereo)
1600 + 1600 Watts RMS   (both channels driven)
Output power stereo mode at  2.66 ohm  (stereo)
1200 + 1200 Watts RMS   (both channels driven)
Output power stereo mode at  2 ohm      (stereo)
1000 + 1000 Watts RMS   (both channels driven)
Output power bridged mode at 16 ohm   (mono)
1700 Watts RMS
Output power bridged mode at 8 ohm     (mono)
3200 Watts RMS
Output power bridged mode at 4 ohm     (mono)
2000 Watts RMS
Overload and short-circuit protection system
Current limited controlled by AGC at 32A per CH.
Overheat protection system
Cut-off  at internal 85 Deg.   Resume at 55 Deg.
Power Supply protection
Soft start - Against all severe voltage fluctuations
AC Input Voltage without affecting max. Output Power
180 V - 240 Volts AC.   (when loading 4 ohms)
Dimensions W x D x H
484 x 322 x 88 mm  (2U.  19" Rack mount )
Weight
7Kg.
