เพาเวอร์แอมป์ Ce-anCe รุ่น CA-2500

คุณสมบัติสินค้า:

Share

Share

CA-2500

• 2 x 250W @ 8 Ohm
• 2 x 400W @ 4 Ohm

Frequency response
20Hz-20KHz, +0,-1dB at watt


TDN+N (20Hz-20KHz)
<0.1% 20Hz-20KHz




Siew Rate

>28V/us

Damping Factor

>280

Output Circuitry

Class H
Class H
Class H
Class H


Signai to Noise Ratio

>95dB
>95dB
>/95dB
>95dB


Cross Talk

>80dB
>80dB
>80dB
>80dB


Input Sensitivity 8Ω

0.775V, 1V, 1.4V


Input Impedance

20 KΩ Balance / 10 KΩ Unbalane


Connectors

Input : XLR Output Speakon connectir


Controls

Front : AC Switch, Ch1 and Ch2 gain honbs


Indicators

Front : STANDBY-orange LED,POWER-Blue LED, SIGNAL-Green LED, CLIP-Red LED


Amplifier Protection

Short circuit,thermal,over load, clip limiter, DC Voltage, Soft start Ultrasonic and RF Protection

Power Requirements

220V
