เพาเวอร์ NTS รุ่น PA - SERIES POWERAMP

คุณสมบัติสินค้า:

Share

Share

PA-400

• ราคา :  5,000 บาท

PA-800

• ราคา :  6,000 บาท

PA-2800

• ราคา :  8,500 บาท

________________________________________________________

PA-400


Technical Specification

Rated Power (Stereo 8Ω /ch.)
100W

Rated Power (Stereo 4Ω /ch.)
150W

Rated Power (Bridge Mono 8Ω)
300W

Frequency Response
20Hz - 20KHz, -3dB @ 100KHz

THD+N
< 0.03% @ 8Ω 1KHz

S/N Ratio
> 90dB

Slew Rate
20V/us

Damping Factor

400

Crosstalk
> 70dB @ 8Ω 1KHz

Input Impedance
20KΩ balanced / 10KΩ unbalanced

Input Sensitivity
0.775V

Class
Class AB

Height
2U

_________________________________________________________

PA-800

Technical Specification

Rated Power (Stereo 8Ω /ch.)
200W

Rated Power (Stereo 4Ω /ch.)
300W

Rated Power (Bridge Mono 8Ω)
600W

Frequency Response
20Hz - 20KHz, -3dB @ 100KHz

THD+N
< 0.03% @ 8Ω 1KHz

S/N Ratio
> 95dB

Slew Rate
30V/us

Damping Factor
400

Crosstalk
> 70dB @ 8Ω 1KHz

Input Impedance
20KΩ balanced / 10KΩ unbalanced

Input Sensitivity
0.775V

Class
Class AB

Height
2U

______________________________________________________________

PA-2800


Technical Specification

Rated Power (Stereo 8Ω /ch.)
400W

Rated Power (Stereo 4Ω /ch.)
600W

Rated Power (Bridge Mono 8Ω)
1200W

Frequency Response
20Hz - 20KHz, -3dB @ 100KHz

THD+N
< 0.03% @ 8Ω 1KHz

S/N Ratio
> 102dB

Slew Rate
40V/us

Damping Factor
400

Crosstalk
> 70dB @ 8Ω 1KHz

Input Impedance
20KΩ balanced / 10KΩ unbalanced

Input Sensitivity
1V

Class
Class AB

Height
2U
