มิกเซอร์ ALTO รุ่น ZMX100fx

คุณสมบัติสินค้า:

Share

Share

สินค้ามีส่วนลดพิเศษ

กรุณาติดต่อทางร้าน !!


095 597 1087



4-CHANNEL MIXER WITH EFFECTS & USB AUDIO INTERFACE

• 4-channel mixer with stereo (2) 1/4
• 16-bit, 44.1/48 kHz signal stereo in / stereo out via USB for easy recording and playback
• (2) XLR inputs with gain trim, switchable high-pass filters, and 48V phantom power
• (4) 1/4
• Compatible with iOS devices via the Apple to USB Camera Adapter (sold separately)
• Dual-band EQ on XLR inputs for accurate tone control
• 15 DSP Alesis effects with footswitch bypass control and aux bus for external processing
• Multicolor LED metering for real-time, visual level feedback
• Headphone output with independent level control for additional monitoring and mixing
• Class-compliant USB for plug-and-play support on both Mac and PC

TECH INFORMATION

Inputs:

Line (CH 1, 2): 10 KΩ input impedance 5.5 mV ~ 4.9 V RMS sensitivity for max output
Mic (CH 1, 2): 600 Ω input impedance balanced 700 mV RMS sensitivity for max output
Line (CH 3, 4): 700 mV RMS sensitivity for max output
HPF (CH 1, 2): 200 Hz (-1 dB), 80 Hz (-3 dB), 20 Hz (-24 dB)
Outputs:

Line: 7 V RMS max
Headphone: 0.5 W into 47 Ω
Signal-to-Noise Ratio:

Line: > 92 dB
(max output; JIS A-weighted) Mic: > 62 dB
Distortion: <0.02%

Frequency Response: Line: 20 Hz – 20 kHz (± 0.5 dB), Mic: 20 Hz – 15 kHz (± 0.5 dB)

Channel Equalizer: Bass: ± 14 dB @ 80 Hz, Treble: ± 14 dB @ 12 kHz

Channel Fader Kill: > 90 dB @ 1 kHz

Crosstalk: > 85 dB @ 1 kHz

Interface: USB 1.1 or higher (stereo in and stereo out)

15 DSP Alesis effects with footswitch bypass control and aux bus for external processing

Power Adapter: 18 VDC, 800 mA

Weight: 1.5lb

Dimensions: 7 3/4 L x 6 W x 2" H
