TADA รุ่น T4
SPECIFICATIONS
8 ohm @ Stereo Output Power : 2350 W
4 ohm @ Stereo Output Power : 5000 W
@ Bridge Output Power : 7500 W
Frequency Response : 20Hz - 35KHz 土 0.5dB
THD+N (20Hz-20KHz) : <0.1%
Slew Rate : 45V/us
Voltage Gain(rated power) : 23dB,26dB,32dB,35dB,38dB,41dB,44dB
Input Sensitivity : 0.775V
Input Impedance : 20KQ balance/10KQ unbalance
Net Weight : 17 Kg
Dimensions : 483 mm x 462 mm X 89mm
Power Requirements 220V-240V/50-60Hz
_______________________________________
SAFETY INSTRUCTIONS:
Read all safety instructions before operating amplifier.
Install equipment as follows:
a. Install in a flat place, not bending or curved.
.- Do not install near water and moisture.
..Place power amplifier away from heat sources, such as radiators or other heat source.
Keep in mind the following when connecting amplifiers
. Read the user manual before connecting the amplifier
..Connect each connection of the amplifier perfectly. If not, it may cause hum, damage, electric
shock in case of disconnection.
.. To prevent electric shocks, do not open top cover.
Connect the power cord with safety after check fo AC power.
