วอลลุ่ม TOA รุ่น AT4012 , AT4120 , AT4030 ติดผนัง Volume Attenuator

คุณสมบัติสินค้า:

Attenuator 12 w - 30w - 120w

Share

AT-4000 Series ถูกออกแบบให้เหมาะกับการใช้งานด้วยมือ โดยมีการศึกษาเรื่องการใช้งานของอุปกรณ์มาอย่างยาวนานให้มีความสบายในการจับและการควบคุมที่ยอดเยี่ยมในทุกๆครั้ง สามารถปรับระดับได้ถึง 8 ระดับโดยมีความต่างกันอยู่ที่ 3dB อีกทั้งยังมาพร้อมกับฟังก์ชั่น Overriding Relay ในตัวพร้อมไฟ LED แจ้งสถานะ

AT-4012

- 12 วัตต์ ราคา 990 บาท

AT-4030

- 30 วัตต์ ราคา 1,740 บาท

AT-4120

- 120 วัตต์ ราคา 1,990 บาท

Input Capacity

12 Watt (4012)

120 Watt (4120)

Attenuations
8 steps (0 dB, -3 dB, -6 dB, -9 dB, -12 dB, -15 dB, -18 dB, OFF)

Override Indicator
Red LED (4-wire connection only)

Overriding Voltage
24V DC, 11mA (4-wire connection only)

Dimensions
86 (W) × 86 (H) × 24 (D) mm

Weight
0.12kg

Color
White (RAL 9016 or equivalent)

Finish
Knob, Cover panel: ABS resin, white (RAL 9016 or equivalent)
Front Panel (Plate): Surface treated steel plate

Terminal
Screw type x 5 (Terminals)

Usable Cable
Cable range: 22 - 14 AWG

_____________________________

TOA AT-4030 AS วอลลุ่มปรับระดับเสียง 30 วัตต์ ปรับระดับเสียง เพิ่ม-ลด ระดับเสียง ติดผนัง 30 วัตต์

วอลลุ่มปรับระดับเสียง TOA ได้รับการออกแบบโดยคำนึงถึงหลักสรีรศาสตร์ของมือมนุษย์ ปุ่มควบคุม Attenuators ของ AT-4000 Series มีขนาดที่จับได้ถนัดมือและการควบคุมที่ยอดเยี่ยมในทุกการหมุน ประกอบด้วยการลดทอน 8 ระดับ ซีรีส์นี้สร้างขึ้นเพื่อให้การควบคุมระดับเสียงที่แม่นยำโดยมีความแตกต่าง 3dB ในทุกขั้นตอน คุณสมบัติรีเลย์ควบคุมในตัวช่วยให้เพจฉุกเฉินซึ่งแสดงโดยไฟ LED เมื่อเปิดใช้งาน
Designed with ergonomics of the human hand in mind, AT-4000 Series Attenuators’ control knob comes in a size that provides comfortable grip and excellent control with every turn. Consisting of 8 steps attenuation, the series is built to provide precision volume control with a difference of 3dB in every step. The built-in overriding relay feature allows emergency paging which is indicated by the LED light when activated.


Input Capacity
30 Watt (Max)
Attenuations
8 steps (0 dB, -3 dB, -6 dB, -9 dB, -12 dB, -15 dB, -18 dB, OFF)
Override Indicator
Red LED (4-wire connection only)
Overriding Voltage
24V DC, 11mA (4-wire connection only)
Dimensions
86 (W) × 86 (H) × 51 (D) mm
Weight
0.45kg
Color
White (RAL 9016 or equivalent)
Finish
Knob, Cover panel: ABS resin, white (RAL 9016 or equivalent)
Front Panel (Plate): Surface treated steel plate
Terminal
Screw type x 5 (Terminals)
Usable Cable
Cable range: 22 - 14 AWG
Accessories
Back Box (85.5 (W) x 85.5 (W) x 60 (D) mm
Plate Mounting Screw x 2
