TOA PE304 ลำโพงติดเพดาน30วัตต์

ตู้ลำโพงผนัง TOA รุ่น PE 304

ตู้ลำโพงผนัง TOA รุ่น PE 304 เสียงดี ราคาถูก





 ENCLOSURE

Bass-reflex type

 RATED INPUT

30 W (100 V, 70 V line, 8 Ω)

 RATED IMPEDANCE

100 V line: 330 Ω (30 W), 500 Ω (20 W), 670 Ω (15 W), 1 kΩ (10 W), 2 kΩ (5 W)



70 V line: 170 Ω (30 W), 250 Ω (20 W), 330 Ω (15 W), 500 Ω (10 W), 1 kΩ (5 W)



8 Ω

 SENSITIVITY

91 dB (1 W, 1 m) (500 - 5,000 Hz, pink noise)

 FREQUENCY RESPONSE

70 - 20,000 Hz (peak -20 dB)

 SPEAKER COMPONENT

12 cm (5") cone-type + balanced dome-tweeter

 SPEAKER CORD

2-core cabtyre cord 5 m (16.4 ft)

 APPLICABLE CABLE

600 V vinyl-insulated cable (IV wire or HIV wire)



Solid copper wire: φ0.8 - φ1.6 mm (equivalent to AWG 20 - 14)



7-core twisted copper wire: 0.75 - 1.25 m㎡ (equivalent to AWG 18 - 16)

 CONNECTION

Push-in connector (bridging terminal-2 branch type)

 FINISH

Enclosure: HIPS resin, off-white (RAL 9010 or equivalent color)



Grille: Surface-treated steel plate net, off-white (RAL 9010 or equivalent color),



paint

 DIMENSIONS

φ186 × 251 (H) mm (φ7.32" × 9.88") (unit only)

 WEIGHT

2.1 kg (4.63 lb) (unit only)

 ACCESSORY

Ceiling bracket …1, Mounting hanger …1, Ceiling cover …1,



Speaker mounting screw (4 × 16)…4
