Digital Mixer มิกซ์ดิจิตอล SoundBest รุ่น SBM20

Mixer Digital SBM20

ระบบ Touch Screen 10 Inch

Master, voice amplifier circuit

16 analog input, 14 digital gain amplifier channels, smooth 0.1dB step gain adjustment, signal through high performance low delay 24-bit analog to digital converter, minimal distortion and ultra-low background noise, multi-function parameter adjustable;Digital gain brings good consistency, can effectively prevent misoperation;These are unmatched by analog mixers.
Voice playback base noise: 30dBu voice playback gain -86.8dBu no recording weight (AP test AES17-20Khz)
Voice play bottom noise: 40dBu voice play gain -80dBu unrecorded weight (AP test AES17-20Khz).



Powerful DSP processor
The digital mixer uses ADSP-21489 450Mhz, which can provide more powerful DSP processing power, such as providing advanced algorithms such as all-pass filter, dynamic balancing DEQ, upgrading or replacing from analog to digital mixer, will be one of your best choices.

Mixing speed
With powerful processing power and advanced functions, can quickly call out the mixing interface, and timely adjustment;Once you start to use it, you can feel the convenience and speed brought by our software operation process design;Convenient and quick operation experience, so that everyone can enjoy the convenience and powerful functions of the digital sound mixing desk.

Touch control system
1280×800 real color capacitive touch screen, digital encoder and special keys constitute the operation panel, can quickly, convenient for all Settings;Friendly software interface, clear navigation design, even without referring to the manual, can also understand the operation, special keys and screen navigation buttons will quickly guide you to each function module;Such as level meter, PEQ, Limiter, USB playback, scene storage, system Settings, etc.

USB mouse error tolerance is prevented because of touch screen
When the touch screen fails, you can insert the standard USB mouse into the USB port and use it immediately without restarting.

13 100mm electric faders
Electric faders are standard on digital mixers, allowing instant control of all channels and main outputs in compact Spaces: 1 LR main channel fader, 12 channel fader and 2 fader layers for easy and fast switching.

2 built-in effectors
For singing, performance field, built-in effect can simplify system wiring;The equipment comes with classic reverberation, large room reverberation and other effect modules;FX sounds can be returned to the mix using a dedicated return channel and do not occupy the mono and stereo input channels.

Scene storage
Scene storage is one of the most practical and significant functions different from the analog sound console. It can store complete scenes, and all scenes can be exported to external storage devices for storage backup.So that all scenes can be called in time later.

PEQ scenario
PEQ scene store mode store for a single input channel, the best state you tune before the show, can be stored to the system, can be called on any input channel;Such as singer, instrument tuning before a performance.

USB playback
It can identify the names of Chinese and English songs in the USB electronic disk, and has the functions of fast forward, next song, quick pause, etc., which is very convenient for field operation;And support to play APE, FLAC, MP3, WAV lossless audio format.

ARM processor +Linux system
Samsung 4418 quad-core 1.4G high-performance ARM processor, easy to drive touch screen display and interface, USB playback, fast startup in 22 seconds;linux system is stable, efficient and virus-free so that it has better security.

Function Description

10 inch capacitive touch screen 1280×800 resolution
13 100mm electric faders
Chinese/English interface can be switched at any time without restarting
Built-in USB recording and playback functions
It can play APE, FLAC, MP3 and WAV lossless audio formats
Built-in 14-channel independent feedback suppressor
With 2 Dcas
iPad touch screen full control with real-time data syncing
Optional WIFI hotspot
Support for simultaneous control of eight terminals
2 built-in effector modules
ARM firmware, DSP firmware can be upgraded through the network or USB resistance disk
Each input channel has 4 sections of parameter equalization, noise gate, feedback suppressor, high and low pass, compression, reverse phase
Each output channel has 8 sections of parameter equalization, high and low pass, compression and reverse phase
Output channel L/R, 6BUS, 2AUX, HeadPhone(L/R)
6 BUS, 2 AUX mixing bus optional fader front and rear (PRE/POST)
Support scene preset function, can export, import USB memory, easy data backup
100 PEQ mode storage
Built-in signal generator: sine wave, pink noise, white noise
Channel parameter copy function, the same channel fast copy data
Connection mode: balanced input and output cannon
8 fader marshalling, 1 system mute button, 3 quick mute buttons
Features panel locking keys (to prevent misoperation)
Channel name can be customized
 Name
Digital mixing station
 Display size
10 inches
 Touch control
Capacitive screen
 Resolution
1280×800
 Master CPU
Samsung 4418 4-core Cortex™-A9
 Boot speed
22 seconds
 Operating system
Linux
 DSP
ADSP-21489 450Mhz
 Analog input
16CH ( 14MIC + 2Line )
 Digital input
S/PDIF, Optical fiber
 Digital output
AES EBU
 USB playback
Play formats APE, FLAC, MP3, WAV
 USB recording
Support recording
 Analog output
L/R+6BUS+2AUX+Headphone(L/R)
 Output base noise
-90dBu unrecorded weight (AP 515 tests AES17-20Khz)
 Distortion degree
0.005%@4dBu 1Khz
 Sex to noise ratio
-108dB no memory power
 Dynamic range
108dB
 Frequency response
20Hz-20 KHZ ±0.5dB
 Maximum input/output level
18dBu (6.2Vrms) Balance
 DCA
√
 Electric pusher
13
 ipad controls
√
 Effector
Two effector buses
 Feedback suppressor
16 channel feedback suppressor
 Output delay
Output delay 1800millisecond
 Ethernet
100M
 RS-232 protocol
Support for RS232 protocol
 WIFI
150M (optional)
 USB mouse
√
 Dimensions (width * depth * height)
535x485x205mm
 Power supply
AC 100v-240v ; 50/60Hz  55W
 Net weight
10.7 kg
 Gross weight
14.9 kg
 Package size
635 * 580 * 335
